Hybrid Power Conversion System (PCS) with Solar Access

Hybrid power conversion system (PCS) with solar access consists of PV control modules and bidirectional DC/AC converter. PV modules increase the voltage produced by solar panel for bidirectional AC/DC converter or to charge battery. The PV controller in PV modules will make full use of the maximum power point (or MMP) to give full play to solar power. Bidirectional AC / DC converter can achieve the power conversion between DC and AC. Furthermore, it can convert AC to DC to charge battery, and convert DC to AC to provide power to loads or back feed the grid. In addition, the hybrid power conversion system with solar access is easy for installation and maintenance.

Bidirectional AC/DC module

Bidirectional AC / DC converter can do the power conversion between DC and AC. Additionally, it can convert AC to DC to charge battery, and convert DC to AC to power to loads or back feed the grid.

Static Transfer Switch

Static Transfer Switch could be shifted within 10ms automatically. Under normal operating condition, the switch is on. When mains power fails, the switch would turn off and the battery system thus shifts to off-grid modes to power loads.

Monitoring System

The system monitors each individual battery cell and records its historical performance.

Maximum Power Point Tracking

PV modules increase the voltage produced by solar panel for bidirectional AC/DC converter or to charge battery. The PV controller in PV modules can make full use of the maximum power point (or,MMP) to give full play to solar power.

Features

• Multiple modes: grid-connected, off-grid, or on and off-grid modes are available.
• Three-level control technology ensures high-quality output of electricity.
• Low voltage transform and reactive power compensation.
• The micro-grid system composed of battery, energy storage inverter, PV solar panel could provide uninterruptible power supply.
• 100% unbalanced load capacity in off-grid operation.
• Continuous 105% rated output power.
• Many power storage inverters can be connected in paralleled way to increase capacity of battery system.
• AC or DC input is acceptable to keep the normal operation of battery system.
• Modular design allows the flexible combination of power storage PCS.
