Smart UPS On-line 10kVA RM/RT 400V

This is a smart on-line UPS system with module power of 10kVA, and input/output method options of 1/1, 1/3, 3/1, 3/3 phase mode, and supports rack-mount or tower mounting options.

DSP-10kVA UPS System
  • Module power: 10kVA
  • Input/output phase mode: 1/1, 1/3, 3/1, 3/3 phase
  • Mounting options: Rack-mount or tower
Smart UPS On-line 10kVA RM/RT 400V
UPS System Technical Parameters
Battery parameter
Battery voltage ±240V
Battery current 20.8A
Maximum charging current 4A
AC input
Input rated voltage One phase three-line 220V、Three-phase four-line+ grounding line 380V
Input voltage range 176VAC-264VAC、304VAC-456VAC
Input power factor 0.99(100% linear load)
Input frequency 40~70Hz
Frequency Synchro range 45Hz~56Hz
Frequency Synchro rated 0.5~2Hz/s
AC output
AC output voltage Single phase: 220VAC/230VAC/240VAC Three phase: 380VAC/400VAC/415VAC
Output power factor 0.8
Output frequency 50/60Hz
Output frequency stability ±0.1%
Output THDU 3%(liner load)
Output voltage accuracy ± 2%
Transient range ±5%(load changing 0%~100%~0%)
Transient duration 20 ms
Peak factor 3:1(rated input)
Output delay at power-on 5~60S
overload 1min 125% rated load
Overall efficiency ≥ 93%
Transfer time Bypass-Inverter ≦ 2ms
Parallel current unbalancedness 5%( ＞50% load )
Communication RS232/USB / SNMP（standard）；SNMP (optional)
Other
Dimension (W*D*H)mm 430*622*132mm
Weight (kg) 25kg
Mounting Rack-mount/tower
Acoustic noise ≦ 58dB
Heat-dissipating method Force air cooling
Protection level IP20
Enclosure material Cladding aluminum galvanized, cold-rolled steel sheet, panel: plastic spraying processing
